Description
This forklift is designed to be used on flat ground, avoiding uneven grounds with potholes or large ramp.
Normal Ambient temperature shall not be higher than +104°F and no lower than -13°F. Fully charge battery before use to avoid damaging cells. Charger plugs into standard 110V-120V outlets.
Charge the forklift once a month even it’s not in use.
Load Capacity 3300lbs
Service Weight (battery incl.)
Height, Mast Lowered
90.4 inch
Max. Lifting Height
130 inch
Height, Mast Extended
157 inch
Fork Lowered Height
2.8 inch
Overall Length
70.3 inch
Overall Width
46.5-62.3 inch
Width Overall Forks
7.8-31.5 inch
Fork Dimension（thickness*width*length）
1.3*3.9*42 inch
Distance Between Forks (inside)
0.1-23.6 inch
Fork Lowered Height
2.8 inch
Turning Radius
52.9 inch
Travel Speed, Laden/Unladen
2.8/3.1 mph
Lift Speed, Laden/Unladen
3.5/5.9 inch/s
Lowering Speed, Laden/Unladen
5.9/4.3 inch/s
